Chevalier 12" x 24" CNC Reciprocating Surface Grinder
Reciprocating Surface GrindersTable-W | 11.75" |
Table-L | 23.625" |
Power | 5 hp |
Grinding Wheel Width | 2" |
Grinding Wheel Dia. | 14" |
Control | CNC (Fanuc OM) |
Dimensions | 106" x 59" x 76" |
ONE USED CHEVALIER 3-AXIS CNC SURFACE GRINDER
Model: FSG-1224ADII
Table size: 11 ¾” x 23 5/8”
Grinding capacity travels: 25 5/8” x 13 ¾” in full Auto
Longitudinal Hydraulic feeds: 16-82 FPM
Auto travel on Cross traverse: 1/8” to 1 ¼” per cycle
Wheel head vertical infeed: 0.000050” to 0.002”, 25 ipm in Rapids
Grinding wheel HP: 5HP, 1,750 rpm/60hz
Grinding wheel size: 14” x 2” wide x 5” bore
Floor space: 106” x 59” x 76”
Weight: 5,951 lbs.
EQUIPPED WITH:
Fanuc OM controls with 3-axis microprocessor control for surface and plunge grinding
12” x 24” fine pole electric chuck with Neutrifier
Tri Mist 850 fume collector
Magnetic swarf removal
Roller guide ways on all three axis
Manual cross feed: 0.000050”
Hydraulic system
Coolant system
SBS Balance System, Md. SB-4500
SN: FA92A001
In plant, Trevor, WI
Fanuc OM controls, Electro Magnetic Fine Pole Chuck, Magnetic swarf removal system, SBS Wheel Balance control system, Tri Mist fume collector
