Makino F3 Precision Hard milling/Graphite VMC

ONE USED MAKINO 3-AXIS HARD MILLING/GRAPHITE VMC

Model: F3
Travels: X, Y, Z: 25.6” x 19.7” x 1.7”
Table size: 33.5” x 19.7”
Table capacity: 1,763 lbs.
Rapid traverse rates: 787 ipm
Spindle RPM: 30,000
Spindle taper: HSK/F63
Spindle HP:
ATC: 30 positions
Wired: 208/240/480v
KVA rating: 45

EQUIPPED WITH:

Pro 5 CNC control with Portable MPG, 12.1” color LCD screen, Super Gi.4 control
Die Mold package, 640 MM storage, 600 Macro common variables, Coordinate system rotation, High speed skip, Rigid tap, Exact stop mode, etc.
Scale feed back for X, Y, & Z
Automatic Air blow
Air dryer
Through spindle air splash
Flood coolant
Centralized Auto grease lube
Graphite package with Central dust collection
Blum Laser
Die Mold Automation Integration
Dust collector interface
3R Robot interface

Specifications are approximate, intended solely as a guide and are not binding. It is the buyers’ responsibility to inspect the goods and ascertain if the specifications, description, and condition of the goods conform to the buyers’ requirements.

New: July 2014

Spindle Run Hours: 17,087

Condition: Excellent

In plant and under power! $ Best offer!
Best regards,

Jerry Ditter, Pres.
